Squadrone – Abrasive Drone Synthesizer

Posted by squaresolid

Squadrone is build by order. Please fill this form for pre-order.

Squadrone – Abrasive Drone Synthesizer is a synthesizer of 3 oscillators and a multimode filter to produce abrasive sound texture. The three oscillators is designed to simultaneously correspond to each other, using feedbacks and FM synthesis. Squadrone is equipped with a Voltage Controlled Multi-mode Filter with Resonance consist of High Pass (6dB) and Low Pass (12dB) that is designed to be able to enter self oscillating mode. The filter offers even more wave shaping and texture ability of the synth. The three oscillators can also be synchronized with an independen oscillator that can also modulate the filter internally.

As for the interface, Squadrone consist of 2 modes, Drone and Cutup. The drone mode will constantly output sounds while in Cutup mode the sound is triggered by 4 silent button. Squadrone is designed to be controlled by one of the buttons or the drone switch. Triggering with 2 or more button is safe for the circuit and can develop interesting sound, or can even clash in to one another and produces silence. Know your machine before you play.

Technical Details:

  • 9-12VDC, center negative & polarity protection
  • Accept CV to control Filter
  • Current consumption between 25-30 mA
  • Artwork by Krisna Widiathama
  • Aluminium enclosure
  • White laser engraving
  • Voltage Controlled Multimode Filter – High Pass (6dB) and Low Pass (12dB)
  • Resonance able to enter self oscillating mode
  • Bakelite knobs in White
  • Silent Push Buttons in White
  • Sync oscillator to control all 3 oscillators
